自动变速箱维修冷却器清洁正告
Automatic transmission service cooler cleaning notice
一、清洁冷却器
1、 Clean the cooler
用自动变速箱冷却清洁器来完全清洁变速箱冷却器和冷却油管；或按以下程序来清洁：
Use the automatic transmission cooling cleaner to completely clean the transmission cooler and cooling oil pipe; or use the following procedure to clean:
A,首要查看冷却油管外观，保证有无折叠、变形等；
A. First, check the appearance of cooling oil pipe to ensure there is no folding, deformation, etc;
B,用化清剂(或同等级商品)喷入回油管直至供油管有化清剂流出，让化清剂在冷却器里边坚持1分钟，保证杂物充沛溶解；
B. Spray chemical cleaning agent (or commodity of the same grade) into the oil return pipe until the chemical cleaning agent flows out of the oil supply pipe. Keep the chemical cleaning agent in the cooler for 1 minute to ensure that the sundries are fully dissolved;
C、用压缩空气吹出溶液，调查溶液色彩；
C. Blow out the solution with compressed air and investigate the color of the solution;
D、可重复B、C过程，直至流出干净液体，然后用风**吹干，保证油道通畅无阻；
D. Repeat process B and C until clean liquid flows out, and then blow dry with air * * to ensure smooth oil passage;
E、更终往回油管内写入变速箱油，然后用风**吹干，重复三次。
E. Finally, write the transmission oil into the oil return pipe, and then dry it with air * * for three times.
二、查看流量
Two. Check the flow
A、自动变速箱装置无缺后，将回油管接入量杯；
A. Connect the oil return pipe to the measuring cup after the automatic transmission device is intact;
B、主动变速箱内加注不少于6公升油；
B. Fill the active gearbox with no less than 6 liters of oil;
C、在“P”档位，发起车辆工作20秒后熄火，查看量杯内排进油量应不少于1升；
C. In the "P" position, start the vehicle to work for 20 seconds and then turn off the engine. Check that the amount of oil discharged into the measuring cup should not be less than 1 liter;
D、达不到需求的，必要时替换水箱和冷却器油管；
D. If it can not meet the requirements, replace the water tank and cooler oil pipe if necessary;
E、更终装好一切油管，查看油面高度，测试路试情况是不是杰出。
E. Finally, install all oil pipes, check the oil level height, and test whether the road test is outstanding.
正告：一切操作必须做好安全防护，并保证油液不会飞溅
Notice: all operations must be well protected and the oil will not splash
